7545

Designed to meet the ICH Q1B Option II standards for visible and UV light exposure, Caron’s photostability chambers are the ideal choice for labs that demand accuracy and consistency.

Key features

  • Complete ICH Q1B Option II testing in half the time of competing chambers

  • Purpose built for photostability testing; this isn’t just a stability chamber with lights

  • Precisely tuned light banks allowing for even powerful light distribution

  • Controllable visible, UV, and relative humidity

  • Temperature range of 10°C to 35°C

  • User-friendly, large-format touchscreen controller simplifies:

    • The setup of custom testing cycles

    • Provides clear, immediate feedback on current operating conditions

    • Gives quick user feedback on how far along the testing cycle is

Simplicity Redefined

At Caron, we understand that complexity should not be a barrier. That's why our photostability chambers boast powerful features including:

  • Intuitive Controls: The 7" color touchscreen control interface is powerful, while also user-friendly.

  • Automatic Operation: Set-and-forget functionality with an automatic cycle for hassle-free operation.

  • Clear Status Display: Easily monitor cycle status, and straightforward setup for custom exposure protocols.

  • Compact Footprint: The compact benchtop design takes up less than 8 square feet, maximizing your valuable lab space.

  • Maintenance Made Easy: Maintenance is a breeze with service alerts and front and rear-mount slide-out assemblies.

Consistent and Precise Outcomes

When it comes to your samples, we know that uniform conditions are non-negotiable. Caron's hardware delivers:

  • Uniform Lighting Conditions: Densely spaced bulbs, reflective aluminum panels, and precise light sensors create a work area with 10-15% VIS uniformity.

  • ICH Compliance: Meets ICH requirements consistently, thereby eliminating the risk of overexposure which is commonly seen in Xenon-powered units.

  • Temperature Control: Built-in tight ±2.5°C temperature uniformity prevents thermal effects, ensuring the accuracy of your test results.

Model
Size
7545
Interior Dimensions 26.9" W x 24.0" D x 28.0" H(683mm W x 610mm D x 711mm H)
Exterior Dimensions 37.7" W x 30.8" D x 45.7" H(958mm W x 782mm D x 1161mm H)
Internal Volume 11 cu. f t. (311L) / Includes Lamp Space
Shelves Total Two (2) Sliding / 26.0" W x 23.1" D x 8" H Each (660mm W x 587mm D x 203mm H)
Shelf Dimensions (660mm W x 587mm D x 203mm H)
Shipping Weight 580 lbs. (700 lbs. With Export Crate)
Model
Size
  7545
  1
2
3
Voltage 115 V 208 / 320V 230 V
Frequency 60Hz 60Hz 50Hz
Current 11.2 A 7.1 A 7.1 A
Model 7545
Size
Temperature Range 10°C to 35°C (Lights On)**
Temperature Control ±0.2°C
Temperature Uniformity ± 2.5°C (Lights On)
Humidity Range 40-70% RH
Humidity Control ± 3%
Lamp Type / UVA RangeFluorescent / Near UV (Black Lamp)
Lamp Type / VIS Fluorescent / Cool White (ISO 10977 Compliant)
Light Detectors UVA and Visual / Calibrated
